Daikin 2AMXF40A + ATXF25G + ATXF25G Air Conditioner Siesta Pro Era 2025 Dual Split 9000 + 9000 Btu A++/A+ WiFi Inverter R32 White
Daikin Multi-Split Model Siesta Pro Era 2025 - ATXF-G 2AMXF-A
Air conditioner kit consisting of 2 indoor units ATXF25G (9000 Btu each), the outdoor unit 2AMXF40A, and 2 remote controls.
Wall-mounted unit with excellent value for money
Integrated Wi-Fi module
Daikin Siesta Multi-Split systems allow up to three indoor units of different sizes to be connected to a single outdoor unit. This is an ideal solution for air-conditioning two or three rooms, even at different temperatures, reducing installation and operating costs. Daikin’s multi outdoor units are robust and reliable, operating with a Swing inverter compressor known for its quietness and high energy efficiency. In cooling mode, the Night Mode can be activated, automatically reducing the operating noise level of the unit by 3 dB(A) during sleeping hours.
The sleek and flat front panel blends seamlessly into any type of decor and is easier to clean. The Wi-Fi module allows control of the indoor unit from anywhere via an app, local network, or the Internet. Seasonal efficiency values reach up to A++ in cooling mode. Choosing an R-32 refrigerant system reduces environmental impact by 68% compared to R-410A systems and leads to direct energy consumption savings due to higher energy efficiency.
Product Features
- Durable and well-designed outdoor units can be easily installed on a roof, terrace, or against an external wall.
- Swing compressor technology ensures low noise levels and high energy efficiency.
- Up to 2 indoor units can be connected to 1 Multi Siesta outdoor unit; each indoor unit operates independently and does not need to be installed in the same room or at the same time. They operate simultaneously in cooling or heating mode.
- Different types of wall-mounted indoor units can be connected.
- R-32 refrigerant system reduces the environmental impact by 68% compared to R-410A systems and directly decreases energy consumption due to high energy efficiency.
- Onecta app: Control your indoor units from anywhere via an app, local network, or the Internet and monitor your energy consumption.
- Ultra-quiet operation up to only 20 dBA.
Technical Specifications – Indoor Unit ATXF25G
Cooling Power: 9000 Btu
Casing Color: White
Unit Dimensions:
- Height: 286 mm
- Width: 770 mm
- Depth: 225 mm
Unit Weight: 8.5 kg
Fan Airflow (Cooling Mode):
- High: 4.4 m³/min
- Medium: 6.1 m³/min
- Low: 8.1 m³/min
- Silent mode: 10.1 m³/min
Sound Power Level: 55.0 dBA
Sound Pressure Level (Cooling Mode):
- High: 40.0 dBA
- Medium: 33.0 dBA
- Low: 26.0 dBA
- Silent mode: 20.0 dBA
Sound Pressure Level (Heating Mode):
- High: 40.0 dBA
- Medium: 34.0 dBA
- Low: 28.0 dBA
- Silent mode: 21.0 dBA
Piping Connections:
- Liquid: 1/4 inch
- Gas: 3/8 inch
Filter Type: Removable / Washable
Control Systems:
- Infrared remote control: ARC480A93
Standard Accessories:
- Installation manual: 1
- User manual: 1
- General safety instructions: 1
- Infrared remote control: 1
- AAA dry batteries: 2
- Remote control holder: 1
- Mounting plate: 1
- Fixing screws for the indoor unit: 2
Power Supply:
- Phase: 1~
- Frequency: 50 Hz
- Voltage: 220-440 V
Technical Specifications – Outdoor Unit 2AMXF40A
Unit Dimensions:
- Height: 550 mm
- Width: 840 mm
- Depth: 330 mm
Unit Weight: 36 kg
Color: Ivory White
Operating Temperature Range:
- Cooling Mode: -10°C to 46°C
- Heating Mode: -15°C to 18°C
Sound Pressure Level:
- Cooling: 46 dBA
- Heating: 48 dBA
Refrigerant Type: R-32
- Charge: 0.88 kg
- GWP: 675.0
Piping Connections:
- Maximum Pipe Length:
- Total: 30 m
- Per single unit: 20 m
- Maximum Height Difference (Indoor-Outdoor): 15.0 m
- Pipe Connections (Liquid): 6.4 mm x 2
- Pipe Connections (Gas): 9.5 mm x 2
Standard Accessories:
- Installation manual: 1
- Drain plug: 1
- Refrigerant charge label: 1
- Multilingual fluorinated greenhouse gas labels: 1
- General safety instructions: 1
Power Supply:
- Phase: 1~
- Frequency: 50 Hz
- Voltage: 220-240 V (Max fuse rating 20A)
