TP-Link DeltaStream 4-port Pizza-box GPON Optical Line Terminal, 1:128, 20000 m, Gigabit Ethernet, 100 - 240 V, 50 - 60 Hz, 38.4 - 72 V
TP-Link DeltaStream 4-port Pizza-box GPON Optical Line Terminal
€1,298.79 Tax included
Codice Articolo: 604574
New product
Garanzia Italia 2 Anni
TP-Link DeltaStream 4-port Pizza-box GPON Optical Line Terminal, 1:128, 20000 m, Gigabit Ethernet, 100 - 240 V, 50 - 60 Hz, 38.4 - 72 V
4-Port GPON Optical Line Terminal
4 GPON Ports,
Supports 512 ONUs
Supports 1:128 splitting ratio for every port—up to 512 ONTs by one device.
Free Centralized Management
Via DeltaStream PON Management System (DPMS)
Easy maintenance and centralized management makes your life a breeze. Configure and update all your devices at once via DeltaStream PON Management System (DPMS), SNMP, CLI and Web UI.
- No Additional Expense
- Improve Management Efficiency And Reduce Maintenance Costs
- The Easy-to-Use Dashboard Ensures Hassle-Free Configuration
Compact Size, Flexible Deployment
Mount in a rack for flexible deployment with all your other products.
Constant Reliability Through Redundant Dual Power Supplies
Dual built-in AC and DC power supplies ensures carrier-class reliability.
TP-Link DeltaStream 4-port Pizza-box GPON Optical Line Terminal. GPON split ratio (max): 1:128, Maximum operating distance (GPON): 20000 m. Upstream ports: Gigabit Ethernet. AC input voltage: 100 - 240 V, AC input frequency: 50 - 60 Hz, DC voltage range: 38.4 - 72 V. Width: 440 mm, Depth: 180 mm, Height: 44 mm
4 GPON Ports,
Supports 512 ONUs
Supports 1:128 splitting ratio for every port—up to 512 ONTs by one device.
Free Centralized Management
Via DeltaStream PON Management System (DPMS)
Easy maintenance and centralized management makes your life a breeze. Configure and update all your devices at once via DeltaStream PON Management System (DPMS), SNMP, CLI and Web UI.
- No Additional Expense
- Improve Management Efficiency And Reduce Maintenance Costs
- The Easy-to-Use Dashboard Ensures Hassle-Free Configuration
Compact Size, Flexible Deployment
Mount in a rack for flexible deployment with all your other products.
Constant Reliability Through Redundant Dual Power Supplies
Dual built-in AC and DC power supplies ensures carrier-class reliability.
TP-Link DeltaStream 4-port Pizza-box GPON Optical Line Terminal. GPON split ratio (max): 1:128, Maximum operating distance (GPON): 20000 m. Upstream ports: Gigabit Ethernet. AC input voltage: 100 - 240 V, AC input frequency: 50 - 60 Hz, DC voltage range: 38.4 - 72 V. Width: 440 mm, Depth: 180 mm, Height: 44 mm
| Caratteristiche | |
| Instradamento statico | Sì |
| Server DHCP | Sì |
| Relè DHCP | Sì |
| Funzione IGMP snooping | Sì |
| Snooping del Multicast listener discovery (MLD) | Y |
| Supporto qualità del servizio (QoS) | Sì |
| Rapporto di divisione GPON (max.) | 1:128 |
| Distanza operativa massima (GPON) | 20000 m |
| Lista di controllo accesso (ACL) | Sì |
| Connettività | |
| Porte a monte | Gigabit Ethernet |
| Quantità porte Ethernet LAN (RJ-45) | 2 |
| Quantità di porte GPON | 4 |
| Quantità porte SFP/SFP+ | 1 |
| Gestione energetica | |
| Tensione di ingresso AC | 100 - 240 V |
| Frequenza di ingresso AC | 50 - 60 Hz |
| tasso di voltaggio DC | 38.4 - 72 V |
| Consumo energetico (max) | 58 W |
| Condizioni ambientali | |
| Intervallo temperatura di funzionamento | 0 - 50 °C |
| Intervallo di temperatura | -40 - 70 °C |
| Range di umidità di funzionamento | 10 - 90% |
| Umidità | 5 - 90% |
| Dimensioni e peso | |
| Larghezza | 440 mm |
| Profondità | 180 mm |
| Altezza | 44 mm |
Informazioni sul produttore
TP-Link Technologies Co., Ltd.
Zeestraat 1
2201 AZ - Noordwijk
Paesi Bassi
CONTATTI
Tel: +31 71 889 1199
Mail: support.eu@tp-link.com
____
Persona responsabile dell’UE
Operatore economico con sede nell’UE che garantisce la conformità del prodotto alle normative richieste.
TP-Link Technologies Co., Ltd.
Zeestraat 1
2201 AZ - Noordwijk
Paesi Bassi
In Stock
Data sheet
- Width
- 440 mm
- Depth
- 180 mm
- Height
- 44 mm
- Operating temperature (T-T)
- 0 - 50 °C
- Storage temperature (T-T)
- -40 - 70 °C
- AC input voltage
- 100 - 240 V
- AC input frequency
- 50 - 60 Hz
- Ethernet LAN (RJ-45) ports
- 2
- Operating relative humidity (H-H)
- 10 - 90%
- Storage relative humidity (H-H)
- 5 - 90%
- Quality of Service (QoS) support
- Yes
- Access Control List (ACL)
- Yes
- IGMP snooping
- Yes
- Power consumption (max)
- 58 W
- DC voltage range
- 38.4 - 72 V
- DHCP server
- Yes
- Static route
- Yes
- Multicast Listener Discovery (MLD) snooping
- Y
- DHCP relay
- Yes
- GPON split ratio (max)
- 1:128
- Maximum operating distance (GPON)
- 20000 m
- Upstream ports
- Gigabit Ethernet
- GPON ports quantity
- 4
- SFP/SFP+ slots quantity
- 1
