TP-Link Omada AX3000 Gigabit VPN Router, Dual-band (2.4 GHz / 5 GHz), Ethernet LAN, Black, Desktop/pole router
TP-Link Omada AX3000 Gigabit VPN Router
€185.96 Tax included
Codice Articolo: 598585
Garanzia Italia 2 Anni
TP-Link Omada AX3000 Gigabit VPN Router, Dual-band (2.4 GHz / 5 GHz), Ethernet LAN, Black, Desktop/pole router
Flexible Wi-Fi Coverage through Business Wired Connectivity
Omada AX3000 Gigabit VPN Router
Ubiquitous Connectivity Starts with WiFi 6
ER706W is an enterprise-grade dual-band wireless router. It’s ideal for remote administration that requires high performance due to the revolutionary combination of the latest WiFi 6 technologies, including HE160, OFDMA, 1024 QAM, and more.‡ Simultaneously supporting 2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz, ER706W’s concurrent transmission rate reaches up to 3 Gbps. Bufferless network experience is at your fingertips.
Up to Five WAN Ports & One USB 3.0 Port for Mobile Broadband
Up to 5× WAN SFP and RJ45 ports allow the router to support various internet access requirements. Multi-WAN Load Balancing distributes data streams according to the bandwidth proportion of every WAN port to raise the utilization rate of multi-line broadband. The USB 3.0 port delivers a higher transmission rate for mobile connectivity. Mobile broadband via a 4G/3G modem is also supported for WAN backup by connecting to the USB port.
Professional Hardware Empowers the Wireless Future
The triple external detachable antenna design grants ER706W excellent wireless coverage, reliable signal strength, and higher receiving sensitivity. It’s easier for users to adjust the quantity and angle of antennas to fit various network environments.
ER706W adopts steel material for higher thermal conductivity and heat dissipation, ensuring operation reliability.
Self-Organizing Network with Omada Access Points
ER706W is able to seamlessly connect to Omada access points that support mesh technology, ideal for large-scale environments. Intelligent self-organization optimizes the best path between ER706W and Omada Access Points while self-healing ensures you stay online even when one AP is disrupted.
High-Security VPN
Pass-through traffic and a variety of VPN protocols, such as IPSec/SSL/Wireguard/PPTP/L2TP VPN, are available on ER706W, giving consumers versatile options. One-click auto IPSec VPN simplifies VPN configuration and facilitates network management and deployment. The router also features a built-in hardware engine to boost VPN performance.
Abundant Security Features
Powerful Firewall
Advanced firewall policies protect your network and data.
Convenient VLAN Support
Create virtual network segments for enhanced security and simplified network management.
DoS Defense
Automatically detects and blocks Denial of Service (DoS) attacks such as TCP/UDP/ICMP Flooding, Ping of Death, and other related threats.
IP/MAC/URL Filtering
Forcefully prevent viruses and attacks from intruders.
IP-MAC Binding
Reserves static IP assignment for clients to defend against ARP attacks and spoofing.
One-Click ALG Activation
One-Click ALG Activation for applications such as FTP, H323, SIP, IPsec, and PPTP.
Omada SDN—The Smarter Cloud Solution for Business Networking
The path to the future of wireless begins with the Omada Software Defined Networking (SDN) solution. As the gateway that seamlessly integrates into the Omada SDN platform, ER706W allows for remote and centralized management, anywhere, anytime.
Easy Management with the Omada App
Users can configure ER706W in both the standalone and controller modes via the Omada app. Standalone management ensures max convenience. No need to set up additional controllers.
Follow the configuration instructions on the app to get set up in minutes. Multi-function configuration is ready to go, including network status monitoring and client management, all from the comfort of a smartphone or tablet.
TP-Link Omada AX3000 Gigabit VPN Router. WAN connection type: SFP. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), WLAN data transfer rate (max): 3000 Mbit/s, WLAN data transfer rate (first band): 574 Mbit/s. Ethernet LAN interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, Cabling technology: 10/100/1000Base-T(X). Security algorithms: WPA, WPA2, WPA3-Enterprise. Routing protocols: OSPF, RIP
Omada AX3000 Gigabit VPN Router
Ubiquitous Connectivity Starts with WiFi 6
ER706W is an enterprise-grade dual-band wireless router. It’s ideal for remote administration that requires high performance due to the revolutionary combination of the latest WiFi 6 technologies, including HE160, OFDMA, 1024 QAM, and more.‡ Simultaneously supporting 2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz, ER706W’s concurrent transmission rate reaches up to 3 Gbps. Bufferless network experience is at your fingertips.
Up to Five WAN Ports & One USB 3.0 Port for Mobile Broadband
Up to 5× WAN SFP and RJ45 ports allow the router to support various internet access requirements. Multi-WAN Load Balancing distributes data streams according to the bandwidth proportion of every WAN port to raise the utilization rate of multi-line broadband. The USB 3.0 port delivers a higher transmission rate for mobile connectivity. Mobile broadband via a 4G/3G modem is also supported for WAN backup by connecting to the USB port.
Professional Hardware Empowers the Wireless Future
The triple external detachable antenna design grants ER706W excellent wireless coverage, reliable signal strength, and higher receiving sensitivity. It’s easier for users to adjust the quantity and angle of antennas to fit various network environments.
ER706W adopts steel material for higher thermal conductivity and heat dissipation, ensuring operation reliability.
Self-Organizing Network with Omada Access Points
ER706W is able to seamlessly connect to Omada access points that support mesh technology, ideal for large-scale environments. Intelligent self-organization optimizes the best path between ER706W and Omada Access Points while self-healing ensures you stay online even when one AP is disrupted.
High-Security VPN
Pass-through traffic and a variety of VPN protocols, such as IPSec/SSL/Wireguard/PPTP/L2TP VPN, are available on ER706W, giving consumers versatile options. One-click auto IPSec VPN simplifies VPN configuration and facilitates network management and deployment. The router also features a built-in hardware engine to boost VPN performance.
Abundant Security Features
Powerful Firewall
Advanced firewall policies protect your network and data.
Convenient VLAN Support
Create virtual network segments for enhanced security and simplified network management.
DoS Defense
Automatically detects and blocks Denial of Service (DoS) attacks such as TCP/UDP/ICMP Flooding, Ping of Death, and other related threats.
IP/MAC/URL Filtering
Forcefully prevent viruses and attacks from intruders.
IP-MAC Binding
Reserves static IP assignment for clients to defend against ARP attacks and spoofing.
One-Click ALG Activation
One-Click ALG Activation for applications such as FTP, H323, SIP, IPsec, and PPTP.
Omada SDN—The Smarter Cloud Solution for Business Networking
The path to the future of wireless begins with the Omada Software Defined Networking (SDN) solution. As the gateway that seamlessly integrates into the Omada SDN platform, ER706W allows for remote and centralized management, anywhere, anytime.
Easy Management with the Omada App
Users can configure ER706W in both the standalone and controller modes via the Omada app. Standalone management ensures max convenience. No need to set up additional controllers.
Follow the configuration instructions on the app to get set up in minutes. Multi-function configuration is ready to go, including network status monitoring and client management, all from the comfort of a smartphone or tablet.
TP-Link Omada AX3000 Gigabit VPN Router. WAN connection type: SFP. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), WLAN data transfer rate (max): 3000 Mbit/s, WLAN data transfer rate (first band): 574 Mbit/s. Ethernet LAN interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, Cabling technology: 10/100/1000Base-T(X). Security algorithms: WPA, WPA2, WPA3-Enterprise. Routing protocols: OSPF, RIP
| Connessione WAN | |
| WAN Ethernet | Sì |
| WAN DSL | No |
| Slot per scheda SIM | No |
| Modem USB compatibile con 3G/4G | Sì |
| Tipo di connessione WAN | SFP |
| Caratteristiche Wireless LAN | |
| Banda Wi-Fi | Dual-band (2.4 GHz/5 GHz) |
| Intervallo di trasferimento dei dati WLAN (max) | 3000 Mbit/s |
| Frequenza di trasferimento dati WLAN (prima banda) | 574 Mbit/s |
| Frequenza di trasferimento dati WLAN (seconda banda) | 2402 Mbit/s |
| Collegamento in rete | |
| Collegamento ethernet LAN | Sì |
| Tipo di interfaccia LAN Ethernet | Gigabit Ethernet |
| Velocità trasferimento Ethernet LAN | 10,100,1000 Mbit/s |
| Tecnologia di cablaggio | 10/100/1000Base-T(X) |
| Port Triggering | Sì |
| DNS Dinamico (DDNS) | Sì |
| Quantità tunnerl VPN | 50 |
| Connettività | |
| Quantità porte Ethernet LAN (RJ-45) | 4 |
| Porta USB | Sì |
| Quantità di porte USB 3.2 Gen 1 (3.1 Gen 1) di tipo A | 1 |
| Jack DC-in | Sì |
| Caratteristiche di gestione | |
| Gestione web-based | Sì |
| Tasto reset | Sì |
| MIMO | Sì |
| Sicurezza | |
| Algoritmi di sicurezza supportati | WPA, WPA2, WPA3-Enterprise |
| Lista di controllo accesso (ACL) | Sì |
| Pianifica l'accesso | Sì |
| Filtro | Sì |
| Filtraggio URL | Sì |
| Registro evento di sistema | Sì |
| Supporto DMZ | Sì |
| NAT (Traduzione dell'indirizzo di rete) | Sì |
| Protocolli | |
| Server DHCP | Sì |
| Universal Plug and Play (UPnP) | Sì |
| Protocollo di routing | OSPF, RIP |
| Design | |
| Tipo di prodotto | Router da tavolo/palo |
| Colore del prodotto | Nero |
| Montabile a parete | Sì |
| Indicatori LED | Sistema, USB, WAN, WLAN |
| Antenna | |
| Design dell'antenna | Esterno |
| Livello di guadagno dell'antenna (max) | 4,5 dBi |
| Qualità dell'antenna | 3 |
| Caratteristiche | |
| Tipo di RAM | DDR4 |
| Memoria flash | 128 MB |
| Certificazione | CE, FCC, RoHS |
| Gestione energetica | |
| Tipologia alimentazione | dC |
| Voltaggio di uscita | 12 V |
| Corrente d'uscita | 2 A |
| Condizioni ambientali | |
| Umidità | 5 - 90% |
| Dimensioni e peso | |
| Altezza | 35 mm |
598585
In Stock
Data sheet
- Width
- 226 mm
- Depth
- 131 mm
- Height
- 35 mm
- Product colour
- Black
- Operating temperature (T-T)
- 0 - 40 °C
- Storage temperature (T-T)
- -40 - 70 °C
- USB port
- Yes
- Product type
- Desktop/pole router
- Ethernet LAN
- Yes
- Ethernet LAN interface type
- Gigabit Ethernet
- Ethernet LAN data rates
- 10,100,1000 Mbit/s
- Ethernet LAN (RJ-45) ports
- 4
- Security algorithms
- WPA, WPA2, WPA3-Enterprise
- LED indicators
- System, USB, WAN, WLAN
- Operating relative humidity (H-H)
- 10 - 90%
- Storage relative humidity (H-H)
- 5 - 90%
- Web-based management
- Yes
- System event log
- Yes
- Access Control List (ACL)
- Yes
- MIMO
- Yes
- DC-in jack
- Yes
- Output voltage
- 12 V
- Output current
- 2 A
- Internal memory
- 512 MB
- Internal memory type
- DDR4
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
- 1
- AC adapter included
- Yes
- Power source type
- DC
- Manual
- Yes
- Reset button
- Yes
- Certification
- CE, FCC, RoHS
- Cabling technology
- 10/100/1000Base-T(X)
- Flash memory
- 128 MB
- Wall mountable
- Yes
- Ethernet WAN
- Yes
- SIM card slot
- No
- 3G/4G USB modem compatibility
- Yes
- Wi-Fi band
- Dual-band (2.4 GHz / 5 GHz)
- WLAN data transfer rate (max)
- 3000 Mbit/s
- WLAN data transfer rate (first band)
- 574 Mbit/s
- WLAN data transfer rate (second band)
- 2402 Mbit/s
- Guest access
- Yes
- Universal Plug and Play (UPnP)
- Yes
- Antenna design
- External
- Antennas quantity
- 3
- DSL WAN
- No
- Port forwarding
- Yes
- Filtering
- Yes
- URL filtering
- Yes
- DMZ support
- Yes
- Network address translation (NAT)
- Yes
- DHCP server
- Yes
- Dynamic DNS (DDNS)
- Yes
- MU-MIMO technology
- Yes
- Antenna gain level (max)
- 4.5 dBi
- WAN connection type
- SFP
- Routing protocols
- OSPF, RIP
- Port triggering
- Yes
- VPN tunnels quantity
- 50
- Schedule access
- Yes
