TP-Link Omada 16-Port 2.5G and 2-Port 10GE SFP+ L2+ Managed Switch with 8-Port PoE+, Managed, L2+, 2.5G Ethernet (100/1000/2500), Power over Ethernet (PoE), Rack mounting, 1U
TP-Link Omada 16-Port 2.5G and 2-Port 10GE SFP+ L2+ Managed Switch with 8-Port PoE+
€688.35 Tax included
Codice Articolo: 597639
Garanzia Italia 2 Anni
TP-Link Omada 16-Port 2.5G and 2-Port 10GE SFP+ L2+ Managed Switch with 8-Port PoE+, Managed, L2+, 2.5G Ethernet (100/1000/2500), Power over Ethernet (PoE), Rack mounting, 1U
Ultrafast 2.5G PoE+ Managed Switch with 10G Uplink for Futuristic Network
2.5G Ports for WiFi 7/6E/6
16× 2.5 Gbps Ports Unlock the Full Potential of WiFi 7/6E/6 APs
10G Lightning-Fast Uplink Connection
2× 10 Gbps SFP+ Slots for High-Bandwidth Connectivity
250W PoE Budget
8× PoE+ Ports with Total 250 W Power Budget
Centralized Cloud Management
SDN Solutions Integration for a Highly Efficient Network
Unlock the Full Potential of WiFi 7/6E/6 with Multi-Gigabit PoE+ Ports
Featuring 8x PoE+ 2.5G ports, the switch is capable of future network expansion and deployment, providing sufficient bandwidth for incoming WiFi 7/6E/6 APs. Designed to use a single Ethernet cable for both data and power transmission, it supports up to 250W total PoE power budget* and flexible installation to fit in various application scenarios.
Enterprise Switch with 10G Uplink
2× 10 Gbps SFP+ slots provide non-blocking switching performance and ultra-low latency, so reliable and lightning-fast connections to server and other switches are easily built.
Software Defined Networking (SDN) with Cloud Access
Omada’s Software Defined Networking (SDN) platform integrates network devices, including access points, switches and gateways, providing 100% centralized cloud management. Omada creates a highly scalable network—all controlled from a single interface. Seamless wireless and wired connections are provided, ideal for use in hospitality, education, retail, offices, and more.
Advanced L3 Features***
An abundance of L2+ and L3 features are supported to help build a highly scalable and robust network, providing a reliable and efficient solution for enterprises, campuses and ISPs.
Secure Networking
Security features include IP-MAC-Port-VID Binding, Port Security, Storm Control and DHCP Snooping to defend against a range of network threats. An integrated list of common DoS attacks is available, making it easier than ever to prevent them. In addition, the Access Control Lists (ACL, L2 to L4) feature restricts access to sensitive network resources by denying packets based on source and destination MAC address, IP address, TCP/UDP ports or VLAN ID. Users’ network access can be controlled via 802.1X authentication, which works with a RADIUS/Tacacs+ server to grant access only when valid user credentials are provided.
Enterprise Level Features
A complete lineup of L2+ features are supported, including 802.1Q VLAN, Port Mirroring, STP/RSTP/MSTP, Link Aggregation Control Protocol, and 802.3x Flow Control. Advanced IGMP Snooping ensures the switch intelligently forwards multicast streams to only the appropriate subscribers, cutting out unnecessary traffic, while IGMP throttling & filtering restrict each subscriber on a port level to prevent unauthorized multicast access. Static Routing is a simple way of segmenting the network and internally routs traffic through the switch for improved efficiency.
Advanced QoS
Voice and video traffic can be prioritized based on IP address, MAC address, TCP port number, UDP port number, and more. With QoS (Quality of Service), voice and video services remain smooth, even when bandwidth is in short supply.
ISP Features
QinQ, L2PT PPPoE ID Insertion and IGMP authentication features are provided, developed with service providers in mind. 802.3ah OAM and Device Link Detection Protocol (DLDP) offer easy monitoring and troubleshooting of Ethernet links.
IPv6 Support
IPv6 functions such as Dual IPv4/IPv6 Stack, MLD Snooping, IPv6 ACL, DHCPv6 Snooping, IPv6 Interface, Path Maximum Transmission Unit (PMTU) Discovery and IPv6 Neighbor Discover guarantee your network is ready for the Next Generation Network (NGN) without upgrading your hardware.
TP-Link Omada 16-Port 2.5G and 2-Port 10GE SFP+ L2+ Managed Switch with 8-Port PoE+. Switch type: Managed, Switch layer: L2+. Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500), Basic switching RJ-45 Ethernet ports quantity: 16, Console port: RJ-45/Micro-USB. MAC address table: 16000 entries, Switching capacity: 120 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1s, IEEE 802.1w. Power connector: AC-in jack. Power over Ethernet (PoE). Rack mounting, Form factor: 1U
2.5G Ports for WiFi 7/6E/6
16× 2.5 Gbps Ports Unlock the Full Potential of WiFi 7/6E/6 APs
10G Lightning-Fast Uplink Connection
2× 10 Gbps SFP+ Slots for High-Bandwidth Connectivity
250W PoE Budget
8× PoE+ Ports with Total 250 W Power Budget
Centralized Cloud Management
SDN Solutions Integration for a Highly Efficient Network
Unlock the Full Potential of WiFi 7/6E/6 with Multi-Gigabit PoE+ Ports
Featuring 8x PoE+ 2.5G ports, the switch is capable of future network expansion and deployment, providing sufficient bandwidth for incoming WiFi 7/6E/6 APs. Designed to use a single Ethernet cable for both data and power transmission, it supports up to 250W total PoE power budget* and flexible installation to fit in various application scenarios.
Enterprise Switch with 10G Uplink
2× 10 Gbps SFP+ slots provide non-blocking switching performance and ultra-low latency, so reliable and lightning-fast connections to server and other switches are easily built.
Software Defined Networking (SDN) with Cloud Access
Omada’s Software Defined Networking (SDN) platform integrates network devices, including access points, switches and gateways, providing 100% centralized cloud management. Omada creates a highly scalable network—all controlled from a single interface. Seamless wireless and wired connections are provided, ideal for use in hospitality, education, retail, offices, and more.
Advanced L3 Features***
An abundance of L2+ and L3 features are supported to help build a highly scalable and robust network, providing a reliable and efficient solution for enterprises, campuses and ISPs.
Secure Networking
Security features include IP-MAC-Port-VID Binding, Port Security, Storm Control and DHCP Snooping to defend against a range of network threats. An integrated list of common DoS attacks is available, making it easier than ever to prevent them. In addition, the Access Control Lists (ACL, L2 to L4) feature restricts access to sensitive network resources by denying packets based on source and destination MAC address, IP address, TCP/UDP ports or VLAN ID. Users’ network access can be controlled via 802.1X authentication, which works with a RADIUS/Tacacs+ server to grant access only when valid user credentials are provided.
Enterprise Level Features
A complete lineup of L2+ features are supported, including 802.1Q VLAN, Port Mirroring, STP/RSTP/MSTP, Link Aggregation Control Protocol, and 802.3x Flow Control. Advanced IGMP Snooping ensures the switch intelligently forwards multicast streams to only the appropriate subscribers, cutting out unnecessary traffic, while IGMP throttling & filtering restrict each subscriber on a port level to prevent unauthorized multicast access. Static Routing is a simple way of segmenting the network and internally routs traffic through the switch for improved efficiency.
Advanced QoS
Voice and video traffic can be prioritized based on IP address, MAC address, TCP port number, UDP port number, and more. With QoS (Quality of Service), voice and video services remain smooth, even when bandwidth is in short supply.
ISP Features
QinQ, L2PT PPPoE ID Insertion and IGMP authentication features are provided, developed with service providers in mind. 802.3ah OAM and Device Link Detection Protocol (DLDP) offer easy monitoring and troubleshooting of Ethernet links.
IPv6 Support
IPv6 functions such as Dual IPv4/IPv6 Stack, MLD Snooping, IPv6 ACL, DHCPv6 Snooping, IPv6 Interface, Path Maximum Transmission Unit (PMTU) Discovery and IPv6 Neighbor Discover guarantee your network is ready for the Next Generation Network (NGN) without upgrading your hardware.
TP-Link Omada 16-Port 2.5G and 2-Port 10GE SFP+ L2+ Managed Switch with 8-Port PoE+. Switch type: Managed, Switch layer: L2+. Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500), Basic switching RJ-45 Ethernet ports quantity: 16, Console port: RJ-45/Micro-USB. MAC address table: 16000 entries, Switching capacity: 120 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1s, IEEE 802.1w. Power connector: AC-in jack. Power over Ethernet (PoE). Rack mounting, Form factor: 1U
| Caratteristiche di gestione | |
| Tipo interruttore | Gestito |
| Livello del commutatore | L2+ |
| Supporto qualità del servizio (QoS) | Sì |
| Gestito in Cloud | Sì |
| Configurazione dei parametri di localizzazione (CLI) | Sì |
| Registro evento di sistema | Sì |
| Supporto MIB | MIB II (RFC1213), Interface MIB (RFC2233), Ethernet Interface MIB (RFC1643), Bridge MIB (RFC1493), P/Q-Bridge MIB (RFC2674), RMON MIB (RFC2819), RMON2 MIB (RFC2021), Radius Accounting Client MIB (RFC2620), Radius Authentication Client MIB (RFC2618), Remote Ping, Traceroute MIB (RFC2925), Support TP-Link private MIB |
| Connettività | |
| Quantità di porte RJ-45 | 16 |
| Tipo di porte RJ-45 | 2.5G Ethernet (100/1000/2500) |
| Quantità di slot del modulo SFP+ | 2 |
| Console port | RJ-45/Micro-USB |
| Connettore di alimentazione | Jack di ingresso AC |
| Collegamento in rete | |
| Standard di rete | IEEE 802.1D, IEEE 802.1s, IEEE 802.1w |
| Supporto 10G | Sì |
| Mirroring della porta | Sì |
| Routing IP | Sì |
| Velocità trasferimento Ethernet LAN | 100,1000,2500 Mbit/s |
| VLAN support | Sì |
| Caratteristiche della LAN virtuale | MAC address-based VLAN, Port-based VLAN, Private VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN |
| Trasmissione dati | |
| Dimensioni tavola MAC | 16000 voci |
| Capacità di commutazione | 120 Gbit/s |
| tasso di inoltro | 89,28 Mpps |
| Instradamento statico | Sì |
| Numero di instradamenti statici | 48 |
| Numero di interfacce IP | 32 |
| Supporto Jumbo Frames | Sì |
| Frame Jumbo | 9000 |
| Buffer di memoria di pacchetto | 12 MB |
| Sicurezza | |
| Caratteristiche DHCP | DHCP client, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 snooping |
| Lista di controllo accesso (ACL) | Sì |
| Funzione IGMP snooping | Sì |
| Algoritmi di pianificazione di coda | SP, WRR+SP, Weighted Round Robin (WRR) |
| Funzioni Multicast | |
| Supporto multicast | Sì |
| Snooping del Multicast listener discovery (MLD) | Y |
| Protocolli | |
| Protocolli di gestione | SNMP v1/v2c/v3, SNTP |
| Protocollo di registrazione GARP VLAN (GVRP) | Sì |
| Design | |
| Montaggio rack | Sì |
| Fattore di forma | 1U |
| Colore del prodotto | Nero |
| Indicatori LED | Sì |
| Numero di ventole | 2 ventola(e) |
| Certificazione | CE, FCC, RoHS |
| Gestione energetica | |
| Alimentazione | AC |
| Fonte di alimentazione inclusa | Sì |
| Tensione di ingresso AC | 100 - 240 V |
| Frequenza di ingresso AC | 50/60 Hz |
| Consumo energetico (max) | 299,4 W |
| Power over Ethernet (PoE) | |
| Supporto Power over Ethernet (PoE) | Sì |
| Quantità di porte Power over Ethernet plus (PoE+) | 8 |
| Potenza Power over Ethernet (PoE) per porta | 30 W |
| Bilancio energetico totale del PoE | 240 W |
| Condizioni ambientali | |
| Intervallo temperatura di funzionamento | 0 - 50 °C |
| Intervallo di temperatura | -40 - 70 °C |
| Range di umidità di funzionamento | 10 - 90% |
| Umidità | 5 - 90% |
| Dissipazione del calore | 1021,64 BTU/h |
| Dimensioni e peso | |
| Larghezza | 440 mm |
| Profondità | 180 mm |
| Altezza | 44 mm |
| Sostenibilità | |
| Conformità alla sostenibilità | Sì |
597639
In Stock
Data sheet
- Width
- 440 mm
- Depth
- 180 mm
- Height
- 44 mm
- Product colour
- Black
- Operating temperature (T-T)
- 0 - 50 °C
- Storage temperature (T-T)
- -40 - 70 °C
- Cables included
- AC
- Power source
- AC
- Package type
- Box
- AC input voltage
- 100 - 240 V
- AC input frequency
- 50/60 Hz
- Networking standards
- IEEE 802.1D, IEEE 802.1s, IEEE 802.1w
- Ethernet LAN data rates
- 100,1000,2500 Mbit/s
- Security algorithms
- HTTPS, SSH, SSH-2, SSL/TLS
- LED indicators
- Yes
- Operating relative humidity (H-H)
- 10 - 90%
- Storage relative humidity (H-H)
- 5 - 90%
- Sustainability compliance
- Yes
- Switch type
- Managed
- Switch layer
- L2+
- Quality of Service (QoS) support
- Yes
- Web-based management
- Yes
- System event log
- Yes
- Basic switching RJ-45 Ethernet ports quantity
- 16
- Power connector
- AC-in jack
- Port mirroring
- Yes
- Flow control support
- Yes
- Link aggregation
- Yes
- Broadcast storm control
- Yes
- Spanning tree protocol
- Yes
- Head-of-line (HOL) blocking
- Yes
- MAC address table
- 16000 entries
- Switching capacity
- 120 Gbit/s
- Packet buffer memory
- 12 MB
- DHCP features
- DHCP client, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 snooping
- Access Control List (ACL)
- Yes
- IGMP snooping
- Yes
- Multicast support
- Yes
- Rack mounting
- Yes
- Power over Ethernet (PoE)
- Yes
- Heat dissipation
- 1021.64 BTU/h
- VLAN support
- Yes
- Rate limiting
- Yes
- MAC address filtering
- Yes
- Form factor
- 1U
- Password protection
- Yes
- Power consumption (max)
- 299.4 W
- Quick start guide
- Yes
- Certification
- CE, FCC, RoHS
- Basic switching RJ-45 Ethernet ports type
- 2.5G Ethernet (100/1000/2500)
- 10G support
- Yes
- Jumbo frames support
- Yes
- Jumbo frames
- 9000
- Loop protection
- Yes
- Power supply included
- Yes
- Power over Ethernet plus (PoE+) ports quantity
- 8
- Console port
- RJ-45/Micro-USB
- Total Power over Ethernet (PoE) budget
- 240 W
- Management protocols
- SNMP v1/v2c/v3, SNTP
- Static route
- Yes
- Cloud-managed
- Yes
- SFP+ module slots quantity
- 2
- Virtual LAN features
- MAC address-based VLAN, Port-based VLAN, Private VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN
- Forwarding rate
- 89.28 Mpps
- Number of static routes
- 48
- SSH/SSL support
- Yes
- BPDU filtering/protection
- Yes
- IP-MAC-Port binding
- Yes
- Number of fans
- 2 fan(s)
- ARP inspection
- Yes
- IP routing
- Yes
- Authentication
- MAC-based authentication, Port-based authentication
- Power over Ethernet (PoE) power per port
- 30 W
- Compliance certificates
- Federal Communications Commission (FCC), RoHS
- Configuring Location Settings (CLI)
- Yes
- Number of IP interfaces
- 32
- Static port security
- Yes
- Authentication type
- AAA, TACACS+
- Queue scheduling algorithms
- SP, WRR+SP, Weighted Round Robin (WRR)
- Multicast Listener Discovery (MLD) snooping
- Y
- GARP VLAN Registration Protocol (GVRP)
- Yes
