TP-LINK AC1200 Wireless MU-MIMO Gigabit Indoor/Outdoor Access Point

11AC Wave 2 Makes Wi-Fi Go Further
Omada
EAP225-Outdoor

Gigabit Wi-Fi Speeds with MU-MIMO Technology
EAP225-Outdoor supports simultaneous dual band speed of up to 1200Mbps. Outfitted with the latest 802.11ac Wave 2 MU-MIMO technology, EAP225-Outdoor can communicate with multiple clients at the same time which making it ideal for high density environment.

Excellent Hardware Designs
With special design of its antenna, appearance, power options and installation methods, EAP225-Outdoor can perfectly fit for different scenarios both indoors and outdoors.

Detachable Antennas
EAP225-Outdoor is designed with 2 Omni-directional detachable antennas, which means other antennas can also be attached for your specific demands.

Delicate Appearance Even Better for Indoor Applications
EAP225-Outdoor is just similar to a cellphone, with dimension: 8.5 × 1.8 × 1.1in. (215 × 46 × 27mm)

Multiple PoE Options for Easy Installation
EAP225-Outdoor supports both 802.3af PoE and Passive PoE power supply, can be either powered by a PoE switch or the provided PoE adapter.

Excellent Hardware Designs
With special design of its antenna, appearance, power options and installation methods, EAP225-Outdoor can perfectly fit for different scenarios both indoors and outdoors.

Flexible Deployment
EAP225-Outdoor can be easily installed on a wall or to a pole with the mounting kits provided.

Wi-Fi That Goes the Distance
With high transmission power and high gain omnidirectional antennas, EAP225-Outdoor provides stable wireless coverage at a range up to 200m+* at 2.4GHz and 300m+* at 5GHz in outdoor settings.

Specially Designed Weatherproof Enclosure for
Outdoor Environment
Rated as IP65 during Ingress Protection testing, a resilient weatherproof enclosure protects the access points against harsh outdoor condition.

Efficient Centralized Network Management
With Omada Controller software, small and medium-sized businesses can take command of hundreds of indoor and outdoor access points all from a single location. It’s network management as it should be - efficient and intuitive.

TP-LINK AC1200 Wireless MU-MIMO Gigabit Indoor/Outdoor Access Point. Maximum data transfer rate: 1200 Mbit/s, Maximum data transfer rate (2.4 GHz): 300 Mbit/s, Maximum data transfer rate (5 GHz): 867 Mbit/s. Security algorithms: 802.1x RADIUS. Output voltage: 24 V, Power consumption (typical): 10.5 W. Placement: Ceiling, Wall, Product colour: White, Certification: CE、FCC、RoHS. Antenna type: External, Antenna direction type: Omni-directional, Antenna features: Detachable antenna

Features
2.4 GHz	Y
5 GHz	Y
Maximum data transfer rate	1200 Mbit/s
Maximum data transfer rate (2.4 GHz)	300 Mbit/s
Maximum data transfer rate (5 GHz)	867 Mbit/s
Ethernet LAN data rates	10,100,1000 Mbit/s
Frequency band	2.4 - 5 GHz
Networking standards	IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n,IEEE 802.3,IEEE 802.3ab,IEEE 802.3af,IEEE 802.3u
MIMO	Y
MIMO type	Multi User MIMO
Rate limiting	Y
Band steering	Y
Airtime Fairness (ATF)	Y
Quality of Service (QoS) support	Y
Security
Security algorithms	802.1x RADIUS
Number of SSID supported	16
Management features
Web-based management	Y
Syslog	Y
Ports & interfaces
Ethernet LAN (RJ-45) ports	1
Power
Power over Ethernet (PoE)	Y
Output voltage	24 V
Power consumption (typical)	10.5 W
Design
Placement	Ceiling, Wall
Product colour	White
Reset button	Y
Certification	CE、FCC、RoHS
Antenna
Antenna type	External
Antenna direction type	Omni-directional
Antenna features	Detachable antenna
Antennas quantity	2
Antenna gain level (max)	4 dBi
Operational conditions
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	-30 - 70 °C
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 90%
Weight & dimensions
Width	215.7 mm
Depth	90.7 mm
Height	52.2 mm
Packaging data
Number of products included	1 pc(s)
AC adapter included	Y
Mounting kit	Y
Quick start guide	Y
Package width	270 mm
Package depth	140 mm
Package height	100 mm
Package weight	640 g
