D-Link DES-1005D Unmanaged Fast Ethernet (10/100) Black

D-Link's DES-1005D is a powerful 5 port 10/100Mbps desktop switch that is an ideal choice for small workgroups.

The DES-1005D allows users to simply plug any port to either a 10Mbps Ethernet or 100Mbps Fast Ethernet network for compatibility, convenience, and faster connection. The switch comes in a small compact size designed for easy installation and high performance. The DES-1005D eliminates unnecessary traffic and relieves data congestion by delivering dedicated bandwidth for each of the five ports.

Each port on the DES-1005D supports automatic MDI/MDIX detection providing true 'plug and play' capability without the need for confusing crossover cables or crossover ports. With the media auto-sensing feature, plug in the network cable to the DES-1005D directly without the need to worry if the end node is a NIC (Network Interface Card) or switch/hub. The DES-1005D also supports flow control and auto-negotiation of half or full duplex transfer modes for each port.

The DES-1005D provides dynamic memory allocation for data flow control to guarantee against possible packet loss. The DSS-5+ uses fast store-and-forward switching to ensure low data latency and prevents error packages from transmitting among segments.

Auto-sensing 10/100 ports
The DES-1005D uses auto-sensing 10/100 Mbps ports, allowing a small workgroup to flexibly connect to Ethernet and Fast Ethernet devices to create an integrated network. These ports detect the network speed and auto-negotiate between 10BASE-T and 100BASE-TX, as well as between full and half-duplex, allowing you to get the maximum speed possible for each device connected to your network.

Auto MDI/MDIX CrossOver
All ports support automatic MDI/MDIX crossover, eliminating the need for crossover cables or uplink ports. Each port can be plugged directly to a server, hub, router, or switch using regular straight-through twisted-pair Ethernet cables.

Flow Control for Secure Transmission
802.3x flow control on each port minimizes dropped packets when the port’s receiving buffer is full. This gives you a more reliable connection for all of your connected devices.

D-Link DES-1005D. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100), Basic switching RJ-45 Ethernet ports quantity: 5. Full duplex. MAC address table: 2000 entries, Switching capacity: 1 Gbit/s. Networking standards: IEEE 802.3,IEEE 802.3u,IEEE 802.3x. Power connector: DC-in jack

Management features
Switch type	Unmanaged
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	5
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Power connector	DC-in jack
Network
Networking standards	IEEE 802.3,IEEE 802.3u,IEEE 802.3x
10G support	N
Copper ethernet cabling technology	100Base-TX,10Base-T
Cable types supported	Cat3,Cat4,Cat5,Cat5e
Full duplex	Y
MAC address auto-learning supported	Y
Data transmission
MAC address table	2000 entries
Supported data transfer rates	10/20/100/200 Mb/s
Switching capacity	1 Gbit/s
Forwarding rate	0.1488 Mpps
Store-and-forward	Y
Maximum data transfer rate	0.2 Gbit/s
Packet buffer memory	0.046875 MB
Design
Rack mounting	N
Stackable	N
Product colour	Black
LED indicators	LAN, Power
Certification	RoHS, FCC, CE
Performance
Plug and Play	Y
Power
Power consumption (typical)	2.5 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)	N
Operational conditions
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-10 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 90%
Heat dissipation	8.528 BTU/h
Weight & dimensions
Width	125.3 mm
Depth	83.4 mm
Height	29.1 mm
Packaging data
Cables included	AC
Manual	Y
Package width	65 mm
Package depth	105 mm
Package height	98 mm
Package weight	170 g
Other features
Power LED	Y
